Electric Underfloor Heating Mat 150w/m2
Underfloor Heating Mat 150w/m2 can be installed beneath most floor types (not just Tiles). They are suitable to be used as a secondary or primary heat source under Tiles, LVT, Karndean or low tog Carpet. We offer a wide range of mat sizes and loose wire cables. Our largest 150w mat is available at 16sqm, which is supplied as a continuous mat – 0.5m in width x 32m in length – The largest heat mat in the UK. Uniquely, both our R-Mats and R-Cables, are patented with a dual Teflon coating (approx. 2mm in thickness), the strongest and most advanced low profile heating element available. They also have an IPX7 Waterproof rating, making them safe for any room.
The heat mats can be laid directly onto a solid wood or concrete subfloor. It is highly recommended insulation be installed, prior to the under floor heating to aid efficiency and the response of the heating kit. Although both our 150w and 200w can usually heat a room and floor on their own, insulation is an integral part of the complete underfloor kit. The thermal boards drastically reduce running costs and the warm-up time of the heating. For new builds, extensions or old problematic floors, we also offer a range of decoupling membranes, preventing possible lateral movement of the floor.
The XPS, Tile backer thermal boards and final floor tiles, should be fixed with a flexible adhesive. We can even supply a two-part specialist self-levelling compound, the choice of the professional, which is used to embed the heating before the flooring is laid. A 3mm depth of self-level or adhesive is required to embed the heating, before Tiling.
150W vs 200W Underfloor Heating Mats – What is a better option for you?
The key difference between 150w and 200w electric heating is the warm-up time. Essentially, the 200w mats or loose wire cables will reach the set temperature more quickly. Therefore, serving better as a primary heat source than the lower-wattage option. It is the recommendation in high heat loss areas like outhouses, conservatories or external colder rooms. The 200w option should always be used if no insulation can be installed, caused of height restrictions or floor thresholds.
The 150w option can still be used as a primary or sole source of heating, as long as over 80% of the available floor is covered. It is vitally important that insulation is installed when opting for the lower wattage, to aid the efficiency and response, as well as increasing the U values and thermal retention in the room.
Importantly, 20sqm of 150w heating can be powered off a 13amp / 240v fuse supply. This option tends to be a better solution in larger areas when the heating is being retrofitted (walls already plastered/rendered) with electrical supplies set in place. The 200w option, would either be separated into 2 zones (powered from 2 thermostats), or alternatively powered off a 25amp or 40amp relay.
Technical Support, Fitting and Warranty Information
For your peace of mind, our heat mats and loose cables are covered with our Lifetime Guarantee. We are here to assist and advise, before or after a purchase has been made. We can help determine the best solution and coverage of heating you require for any project. Our technical team have over 50 years of combined knowledge and expertise, in the installation and supply of electric heating. Therefore, there is no question or query we wouldn’t be able to answer.
In the unlikely event the heating develops a fault or stops working after installation, we offer free technical support over the phone. In most instances, we can help determine how this may have been caused, resolving most issues with you over the phone. If an onsite repair needs to be done, we have a specialist team who can locate and repair faults under any floor. Repairs can usually be rectified quickly and efficiently, with minimal disruption to your installation or daily routines.
In essence, electric heating is very basic how it operates, the only mechanical/moving parts of the kit being the thermostat controllers. Therefore, when installed correctly and the heating signed off by a qualified electrician, your product is covered with our Lifetime Guarantee.
|Features / Technical Specifications|
|150w/sqm output / Dual Core||Lifetime Warranty|
|Secondary Or Primary Heat||Mat width 0.5m (largest mat 16sqm / 0.5m x 32m)|
|Double insulated Element||Ultra thin & durable heating element with high thermal capacity|
|Supplied with fixing tape||Low Profile – 2mm Heat Element|
|Easy and quick to lay||Pre-spaced wire (to determine wattage) attached to tough self-adhesive fibreglass mesh backing|
|Fully sheathed and earthed elements||Teflon insulated with earth shield heating element|
|Suitable For Most Floors||Compatible With SF Decoupling|
|2.5m long cold / connection tails||3mm long Floor sensor probe / 10k Ohms thermistor (supplied with all thermostats or purchased individually)|
|Enhanced With XPS Insulation||Or Tile Backer Boards|
|Full fitting instructions||Technical Free Phone Help Line|
|Free Technical Assistance||IPX7 Waterproof Rating|
|Operating Voltage 230/240V – 50Hz||Next working day delivery service (when ordered before 12 pm)|
Highly Recommended With This System
At Roma Heating we offer a free design service to make the whole process a little easier. Our time and advice are free and we can recommend the best underfloor heating system for you.
